Basic Product Specifications
| Specifications | Details |
|---|---|
| Product Type | 9 Legs Single Sided Lightweight Pallet |
| Dimensions (L×W×H mm) | 1200 x 1000 x 140 |
| Structure | 9 Legs |
| Deck | Grid Top |
| Deck Type | Single Sided |
| Manufacturing Process | One-Piece Injection Molding |
| Pallet Weight | Approx. 7.8 kg |
| Dynamic Capacity | 500 kg |
| Static Capacity | 2,000 kg |
| Forklift Entry | 4-Way Entry |
| Pallet Jack Entry | 4-Way Entry |
| Container Loading | Approx. 400 pcs / 20FT; 1,000 pcs / 40HQ |
| Application | Export, Warehousing, Logistics |
| Color | Customizable |
| Logo / Printing | Customizable |
Main Features of 9 Legs Lightweight Pallet
1. Ultra-Light 7.8 kg
At only approximately 7.8 kg, this pallet is significantly lighter than many standard industrial plastic pallets. The low tare weight helps reduce the amount of pallet weight included in each shipment and makes empty pallet handling easier in warehouses, loading areas, and export operations.
2. Nine-Leg Grid Structure
The pallet uses a 9-leg support structure combined with a ventilated grid-top deck. This configuration reduces unnecessary material while maintaining a 1200 x 1000 mm loading footprint, making it suitable for applications where low pallet weight is more important than heavy-duty load capacity.
3. 500 kg Dynamic Load
The standard pallet supports up to 500 kg dynamic load and 2,000 kg static load according to the supplied specifications. This capacity makes it suitable for lightweight cartons, bags, packaged products, and general cargo during routine warehouse and transportation operations.
4. One-Piece Molded Design
Manufactured as a one-piece injection-molded pallet, the pallet does not require welded assembly between the main structural components. The integrated 9-leg design provides a consistent structure while keeping the total pallet weight at approximately 7.8 kg.
5. Four-Way Entry
The pallet provides 4-way forklift and pallet jack entry, allowing access from all four sides. This improves handling flexibility in warehouses and loading areas where pallets may need to be approached from different directions.
6. High Container Efficiency
The lightweight structure provides a major advantage for high-volume export orders. Approximately 400 pallets can be loaded into a 20FT container and up to 1,000 pallets into a 40HQ container, helping maximize pallet quantity per shipment and reduce transportation cost per unit.
Applications of Lightweight Plastic Pallet
1. Export Shipping
The 7.8 kg pallet weight makes this model particularly suitable for export applications where pallet tare weight and container utilization affect total logistics cost. Its high loading quantity of approximately 1,000 pcs per 40HQ container also supports large-volume international shipments.
2. General Warehousing
The pallet can be used for cartons, bags, packaged consumer goods, and other relatively lightweight products stored on warehouse floors. Its 500 kg dynamic capacity and 2,000 kg static capacity cover many general-purpose storage and handling requirements.
3. Logistics Distribution
With 4-way entry, the pallet can be picked up from any side by compatible handling equipment. This makes it practical for distribution centers, loading zones, sorting areas, and short-distance warehouse transportation.
4. Lightweight Cargo
The 1200 x 1000 mm footprint provides a large loading surface while maintaining only 7.8 kg of pallet weight. It is suitable for lightweight packaged goods where reducing pallet tare weight is a priority.
5. High Volume Orders
For large pallet purchases, the container loading capacity becomes an important cost factor. With approximately 400 units per 20FT and 1,000 units per 40HQ, this model is suited to bulk export orders where shipping efficiency and pallet unit cost need to be controlled.
Customization Options
The 1200 x 1000 9 Legs Single Sided Lightweight Pallet can be customized according to your logistics requirements.
Available options include:
- Custom pallet colors
- Logo printing and pallet identification
- Packaging with stretch film or cartons
- Structural adjustments for specific cargo requirements
- Customized shipping and packing solutions
For applications involving heavier loads, customers should provide the cargo weight, loading method, handling equipment, and support conditions so the appropriate pallet model can be selected.
FAQs
1. How much does the 1200 x 1000 lightweight pallet weigh?
The standard pallet weighs approximately 7.8 kg, making it suitable for applications where reducing pallet tare weight is a priority.
2. What is the load capacity of this pallet?
The supplied specifications list a 500 kg dynamic capacity and 2,000 kg static capacity. Actual performance depends on load distribution, support conditions, and handling conditions.
3. Why use a 9-leg lightweight pallet?
The 9-leg structure provides multiple support points while keeping the pallet lightweight. Combined with the grid-top design, it helps maintain a 7.8 kg pallet weight for export and general logistics applications.
4. Can the pallet be handled from all four sides?
Yes. The pallet is designed with 4-way forklift and pallet jack entry, allowing handling equipment to access the pallet from four directions.
5. How many pallets can fit in a container?
Approximately 400 pallets can be loaded into a 20FT container, while a 40HQ container can hold around 1,000 pallets, depending on the actual loading and packaging method.
6. Is this pallet suitable for heavy-duty applications?
This model is designed as a lightweight pallet with a specified 500 kg dynamic and 2,000 kg static capacity. For heavy-duty loads or pallet racking, a reinforced or heavy-duty plastic pallet with a higher tested capacity would be more appropriate.
