Product Specifications
| Specification | Details |
|---|---|
| Material | HDPE / PP |
| Dimensions | 1400 × 1400 × 150 mm |
| Manufacturing Process | One-Piece Injection Molding |
| Weight | 21.5 kg |
| Pallet Structure | Full Perimeter |
| Base | Full Perimeter |
| Deck | Vented Grid Deck |
| Forklift Entry | 4-Way Entry |
| Pallet Jack Entry | 4-Way Entry |
| Rackable | Yes |
| Stackable | Yes |
| Reusable | Yes |
| Static Load Capacity | Up to 4,000 kg |
| Dynamic Load Capacity | Up to 1,000 kg |
| Rack Load Capacity | Up to 1,000 kg |
| Steel Reinforcement | Optional |
| Available Colors | Blue, Black, Orange, Grey, Custom |
| Container Loading | Approx. 68 / 168 pcs |
Why Choose This 1400 x 1400 Plastic Pallet?
Large 1400 x 1400 mm Loading Surface
The 1400 x 1400 mm pallet size provides substantially more deck area than common smaller pallet formats. It is particularly useful for large cartons, machinery components, industrial parts, and loads that require additional pallet surface for stable positioning.
A large pallet footprint can also reduce the need for placing multiple smaller pallets under oversized cargo, depending on the load configuration.
Full Perimeter Base for Stable Support
The full perimeter base creates continuous support around the lower edge of the pallet. This structure helps distribute load forces more evenly and provides a stable contact structure during floor storage and rack placement.
For warehouse applications where pallet support conditions matter, the full perimeter design provides a more continuous base than open-bottom configurations.
Designed for Rack Storage
This is a rackable plastic pallet designed for use with suitable pallet racking systems.
The rated rack capacity is up to 1,000 kg under specified conditions. Actual rack performance can vary depending on beam spacing, pallet orientation, load distribution, support conditions, and cargo weight.
For this reason, rack compatibility should be confirmed against the actual warehouse rack configuration before use.
4-Way Forklift and Pallet Jack Entry
The pallet features four-way entry, allowing forklifts and pallet jacks to approach the pallet from all four directions.
This design provides greater flexibility for:
- Warehouse transportation
- Loading and unloading
- Rack positioning
- Floor stacking
- Internal material handling
Four-way entry can be especially useful in large warehouses where pallets move between multiple storage and handling areas.
One-Piece Injection-Molded Construction
The pallet is manufactured through one-piece injection molding, integrating the deck and base into a single molded structure.
This construction eliminates assembled pallet components and provides consistent overall dimensions of 1400 × 1400 × 150 mm. It is suitable for repeated handling in warehouses, manufacturing facilities, distribution centers, and logistics operations.
Heavy-Duty Load Performance
The pallet provides the following rated capacities:
Static load: up to 4,000 kg
Dynamic load: up to 1,000 kg
Rack load: up to 1,000 kg
Static load refers to a pallet carrying a stationary load under appropriate support conditions. Dynamic load relates to handling and transportation conditions, while rack load applies when the pallet is supported by warehouse racking.
Actual load performance depends on pallet condition, load distribution, handling equipment, rack design, temperature, and other operating conditions.
Applications
Warehouse Racking
The rackable structure makes this pallet suitable for warehouses and distribution centers using pallet racking systems. Its large footprint can accommodate bulky unit loads while providing four-way handling access.
Industrial Storage
The 4,000 kg static capacity makes this pallet suitable for stationary storage applications involving heavy industrial products, machinery parts, packaged materials, and other high-weight cargo.
Manufacturing
The 1400 x 1400 mm loading area provides additional deck space for manufacturing applications where products, components, or finished goods exceed the footprint of standard pallets.
Typical applications may include:
- Automotive components
- Machinery parts
- Industrial equipment
- Metal products
- Packaged materials
- Large manufactured components
Distribution and Logistics
The reusable construction and four-way entry make the pallet suitable for repeated movement between production areas, warehouses, distribution centers, and loading zones.
Oversized and Bulky Cargo
Large-format plastic pallets can be useful when the cargo requires more loading surface than standard pallet sizes provide. The 1400 x 1400 mm footprint offers additional space for positioning large or irregularly shaped loads.
How to Use the 1400 x 1400 Rackable Plastic Pallet Safely
The rated load capacity should always be considered together with the way the pallet is used.
For floor storage, the load should be distributed as evenly as possible across the deck. Highly concentrated loads may create localized stress even when the total cargo weight is below the rated capacity.
For rack storage, the actual rack configuration is particularly important. Beam spacing, support width, pallet orientation, load distribution, and unsupported span can all affect pallet performance.
Before placing the pallet into a warehouse racking system, confirm that the pallet dimensions and rack capacity are suitable for the intended application.
Steel-Reinforced Configuration
For applications requiring additional structural support, this 1400 x 1400 plastic pallet can be manufactured with optional steel reinforcement.
Steel tubes can increase structural stiffness for demanding applications, particularly where higher support requirements or greater loads are involved.
The reinforcement configuration should be selected according to:
- Required rack load
- Cargo weight
- Rack beam spacing
- Storage method
- Handling conditions
- Expected frequency of reuse
Contact us with your rack dimensions and load requirements so the appropriate reinforced configuration can be evaluated.
Custom Plastic Pallet Options
As a plastic pallet manufacturer, Prefaceplast can provide customized pallet solutions for different warehouse and logistics requirements.
Available options include:
Custom dimensions
Pallet sizes can be adjusted for specific cargo footprints, equipment, or storage systems.
Custom colors
Standard colors include blue, black, orange, and grey, with custom colors available for identification or branding.
Logo and identification marking
Company logos, identification marks, and other product information can be incorporated according to the production configuration.
Steel reinforcement
Optional steel reinforcement is available for applications requiring additional structural support.
Packaging options
Packaging solutions can be discussed according to shipment method and customer requirements.
1400 x 1400 Plastic Pallet Manufacturer
Prefaceplast manufactures plastic pallets for warehouse storage, industrial handling, transportation, and export logistics applications.
For the 1400 x 1400 Rackable Full Perimeter Plastic Pallet, customers can specify pallet color, reinforcement requirements, identification markings, and other customization options according to the application.
When requesting a quotation, providing the following information can help determine the most suitable pallet configuration:
- Cargo weight
- Static or dynamic loading requirements
- Rack load requirement
- Rack beam spacing
- Forklift or pallet jack type
- Required pallet quantity
- Operating environment
This information allows the pallet structure and reinforcement configuration to be evaluated against the actual working conditions.
Frequently Asked Questions
Is the 1400 x 1400 plastic pallet rackable?
Yes. This pallet is designed as a rackable plastic pallet and has a rated rack capacity of up to 1,000 kg under suitable conditions. Rack compatibility should be confirmed according to beam spacing, support conditions, pallet orientation, and actual cargo weight.
What is the load capacity of the 1400 x 1400 pallet?
The rated capacity is up to 4,000 kg static, 1,000 kg dynamic, and 1,000 kg in racking applications. These ratings are application-dependent and should be evaluated against actual loading and support conditions.
Can the pallet be reinforced with steel?
Yes. Optional steel reinforcement is available. The reinforcement configuration can be selected according to rack requirements, cargo weight, and operating conditions.
Is a 1400 x 1400 pallet suitable for oversized products?
Yes. The 1400 x 1400 mm footprint provides a larger loading area than many standard pallet sizes, making it suitable for bulky products, machinery components, industrial materials, and oversized cargo.
Is this pallet reusable?
Yes. The pallet is designed for repeated use in warehouse circulation, logistics operations, return transport, and storage applications.
What material is used to manufacture the pallet?
The pallet can be manufactured from HDPE or PP, depending on the required application and product configuration.
Does the pallet support pallet jack handling?
Yes. The design provides 4-way pallet jack entry, allowing access from all four sides under suitable operating conditions.
Can the color be customized?
Yes. Blue, black, orange, and grey are available, while custom colors can also be discussed for specific customer requirements.
